| TECHNICAL SPECIFICATIONS | 800 | 900 | 1000 | 1100 | 1200 | |
|---|---|---|---|---|---|---|
| CNC | Mod. | Fagor (Fanuc / Siemens / Heidenhain) | ||||
| Height of centres | mm | 800 | 900 | 1000 | 1100 | 1200 |
| Swing over bed | mm | 1600 | 1800 | 2000 | 2200 | 2400 |
| Swing over cross slide | mm | 1200 | 1400 | 1600 | 1800 | 2000 |
| Distance between centers | mm | 2000… 16000 | ||||
| Bed width | mm | 1100 | ||||
| Number of guideways | N. | 3 (2+1) | ||||
| Maximum weight of workpiece between centers | Kg | 18000 | ||||
| Spindle bore | mm | 130 | ||||
| Spindle nose | Asa | 15″ (20″) | ||||
| Speed ranges (Automatic) | N. | 4 | ||||
| Spindle speed range | rpm | 0:400 | ||||
| Main motor power (S6 – S1) | Kw | 71/51 (100/71) | ||||
| Cross slide travel | mm | 1200 | ||||
| X-Z axis rapid traverse | m/min | 8 | ||||
| Tailstock quill diameter | mm | 240 rotating quill | ||||
| Tailstock quill travel | mm | 300 | ||||
| Tailstock quill taper | Morse | 80; 1:7 | ||||
| WEIGTH | 800 | 900 | 1000 | 1100 | 1200 | |
|---|---|---|---|---|---|---|
| Weight of the lathe of 3000 mm (D.B.C.) | Kg | 27000 | 29000 | 31000 | 33000 | 35000 |
| Each additional meter | Kg | +2500 | ||||
