| TECHNICAL SPECIFICATIONS | 180 | 215 | 250 | |
|---|---|---|---|---|
| Height of centres | mm | 180 | 215 | 250 |
| Swing over bed | mm | 360 | 430 | 500 |
| Swing over cross slide | mm | 190 | 240 | 300 |
| Distance between centres | mm | 1000-1500 | ||
| Bed width | mm | 290 | ||
| Spindle bore | mm | 52 | ||
| Spindle nose | Camlock | 6″ | ||
| Infinitively variable spindle speeds (Inverter) | rpm | N. 6 ranges from 60 up to 2000 rpm | ||
| Main motor power | Kw | 4 (5.5) | 5.5 (7.5) | |
| Range of longitudinal feeds | mm/rev | (38) 0.05 – 1.50 | ||
| Range of transversal feeds | mm/rev | (38) 0.025 – 0.75 | ||
| Range of threads Metric | mm | (30) 0.45 – 20 | ||
| Range of threads Whitworth | T.P.I. | (35) 80 – 13/4 | ||
| Range of threads Module | mm | (25) 0.25 – 10 | ||
| Range of threads Diametral Pitch | DP | (30) 160 – 31/2 | ||
| Cross slide travel | mm | 240 | ||
| Top slide travel | mm | 130 | ||
| Tailstock quill diameter | mm | 60 | ||
| Tailstock quill travel | mm | 130 | ||
| Tailstock quill taper | Morse | 4 | ||
| WEIGTH | 180 | 215 | 250 | |
|---|---|---|---|---|
| T x 1000 | Kg | 2000 | 2100 | 2300 |
| T x 1500 | Kg | 2300 | 2400 | 2600 |
